SB Standard Door Mount Pet Dog Door Dual Flap

Product Specifications

Feature	Details

Mounting Style Door Mount (Compatible with standard door thicknesses: 1 1/4″ to 2″) Flap Design Dual Flap for enhanced insulation and energy efficiency Material Durable, weather-resistant construction Flap Material Flexible, sturdy material for repeated use Size Options – Small: 7″ x 11″
– Medium: 10.5″ x 15″
– Large: 13″ x 20″
– Extra Large: 15″ x 23″ Security Features Sturdy locking mechanism for added safety and control Insulation Dual flaps provide superior insulation against drafts and heat loss Weatherproofing Tight seals to prevent water, wind, and debris from entering Installation Easy, DIY installation; includes pre-drilled pilot holes and necessary hardware Block-Off Panel Removable block-off panel with pin lock for controlled access Magnet Adjustment Adjustable magnets ensure a precise seal, regardless of weather or flap size Usage Suitable for residential and commercial applications Colors Available in White and Bronze Included Accessories One-Way Security Screws, Phillips Head Screws, Allen Wrench

Check Package Contents

Before beginning installation, confirm that your package includes all necessary parts and tools.

Choose the Installation Location

Identify a suitable spot for the door mount. Ensure there is adequate vertical space for the block-off panel to be lifted out completely.

Position the rough opening at least 3 inches away from the edge of the door to maintain its structural integrity.

Trace the Opening

Place the flange of the pet door against the door and trace its perimeter with a pencil. This outline will serve as the dimensions for the rough opening.

Cut the Opening

For Wood Doors:

Drill two diagonal corners using a ⅞-inch paddle bit or a 5/16-inch regular bit. If using a regular bit, drill three close-together holes and elongate them until connected to insert the reciprocating saw blade.

Carefully cut along the traced lines to create the opening.

For Metal Doors:

Follow the same instructions as for wood doors but use a blade specifically designed for cutting metal.

Prepare the Door Frames

Separate the interior and exterior frames of the pet door. Remove the block-off panel from the inner frame.

Insert and Align Frames

Insert the inner frame (the one with the block-off panel) into the cut opening from the interior side of the door.

Align the exterior frame on the opposite side, sleeving the two frames together to fit securely around the door.

Secure the Frames

Using the pre-drilled pilot holes and the supplied drill bit, insert one screw to temporarily hold the frames in place. Ensure the pet door is level before tightening the screw completely.

Insert and tighten the remaining screws using the pilot holes as guides. For added security, use the provided One-Way Security Screws or Phillips head screws.

Seal the Edges

After installation, fill any gaps or seal the edges with caulking to enhance weatherproofing and prevent drafts.

Your SB Standard Door Mount Pet Door Dual Flap is now installed and ready for use!

General Use Information

1. Block-Off Panel Operation

2. To secure the block-off panel, slide it into place and fasten it using the pin lock.
3. When removing the panel, gently pull the pin lock inward while lifting the panel. This ensures the tight-fitting panel does not touch the unit’s frame during removal, preserving the panel and lock mechanism.

Using the Pin Lock

To Retract: Pull on the knob and turn it clockwise (right) approximately a quarter turn to retract the lock.

To Lock: Continue turning the knob another quarter turn to extend the lock into the locked position using spring tension.

Important: Do not turn the knob counterclockwise (left), as this will loosen the pin lock and render it inoperable.

Thumbscrew Maintenance

The flaps are secured with factory-tightened thumbscrews. With regular use, these screws may loosen over time.

Regularly check the thumbscrews for tightness and retighten them as needed using the included Allen wrench.

Magnet Adjustment

The pet door features adjustable magnets to ensure a precise seal, regardless of weather conditions or flap size changes over time.

The magnets are pressure-fitted into an aluminum carrier within the frame rail. To adjust the magnet, use pliers to gently lift it out of the frame rail. Cover the magnet and carrier with a towel to prevent scratching during this process.

Only lift the magnet enough to make contact with the strike plate on the flap.

If the magnet carrier becomes loose, pry the two legs of the magnet apart slightly and reinsert it into the frame rail.

Proper magnet adjustment is achieved when there is zero airspace between the magnet and the strike plate.

With these steps, your SB Standard Door Mount Pet Door Dual Flap is now ready for use, offering security and easy access for your pets.

Disclaimer

Child Safety: Security Boss Manufacturing advises that households with young children exercise caution when allowing them near pet doors. Although our pet doors include locking panels and security features to minimize risks, they do not replace the need for proper parental supervision.

Installation: For those choosing to install their own pet door, we recommend wearing eye protection and having a good understanding of the tools and procedures required for safe installation.

Magnets: Most pet doors utilize magnets to operate and secure the flaps. If you have certain medical devices, such as a pacemaker, consult with your physician before installation or use of the pet door.

Shipping and Return Policy

Returns Policy

Standard Returns: Products that are new, unopened, and uninstalled can be returned within 30 days of the shipment date, subject to a 16% restocking fee. For returns requested between 30 to 60 days, Security Boss Manufacturing reserves the right to refuse the return. If accepted, the product must still be new, unopened, and uninstalled, and a 26% restocking fee will apply.

Manufacturer Defects: Security Boss Manufacturing covers 100% of returns or exchanges due to manufacturer defects.

Custom Products: All custom Security Boss products are non-returnable and non-refundable.

Refund Processing: Refunds are typically processed within four weeks of receiving your package. This period includes transit time (5-10 business days), return processing (3-5 business days), and bank processing time for refunds (5-10 business days).

Return Instructions: To initiate a return, please contact us with your order number and product details. We will provide you with instructions on how to return the item.

Shipping Information

Shipping Locations: We ship to virtually any address worldwide. Some restrictions apply, and certain products may not be eligible for international shipping.

Shipping Estimates: Shipping and delivery dates are estimated based on product availability and the shipping options chosen. These estimates are provided during the checkout process.

Shipping Rates: Shipping costs are calculated based on the weight of the items. For accuracy, weights are rounded up to the next full pound in accordance with shipping company policies.

FAQs – SB Standard Door Mount Pet Door Dual Flap

What is so special about the SB Standard Door Mount Pet Door Dual Flap?

The SB Standard Door Mount Pet Door Dual Flap offers superior insulation and energy efficiency with its dual-flap design. It features a robust locking mechanism for added security, is available in multiple sizes to accommodate various pets, and is constructed from high-quality materials for long-lasting durability.

How do I choose the right size pet door for my dog?

Measure your pet’s shoulder height and add 2 inches to ensure the door’s top opening is slightly taller. The bottom should be at a comfortable step-over height. Choose the door size based on these measurements and the product’s available dimensions.

Does the SB Standard Pet Door help with weatherproofing?

Yes, the dual-flap design provides a tight seal that effectively blocks drafts, wind, and water, maintaining indoor temperatures and improving energy efficiency.

Can the SB Standard Pet Door be installed on a sliding glass door?

No, this model is designed specifically for standard door mount installations. For sliding glass doors, Security Boss offers alternative models tailored for such surfaces.

Is professional installation required for the pet door?

Professional installation is not required but recommended if you’re not familiar with construction tools. The product includes detailed instructions for a straightforward DIY installation on standard doors.

Can the pet door be adjusted for pets of different sizes?

While the pet door cannot be resized, selecting the appropriate size during purchase ensures comfortable use for your pet. For multi-pet households, choose a size that accommodates the largest pet.

How often do I need to replace the flaps on the pet door?

The flaps are built for durability, but their replacement frequency depends on usage and weather exposure. Regular inspection and maintenance, including tightening screws and adjusting magnets, can extend their lifespan.

Does the pet door provide any noise reduction?

Yes, the dual-flap design offers an added layer of insulation that helps reduce outdoor noise, contributing to a quieter indoor environment.

How does the pet door’s locking mechanism work?

The locking mechanism features a block-off panel secured by a pin lock. You can easily retract or lock the pin by turning the knob. This system provides control over your pet’s access and enhances home security.

Can the SB Standard Pet Door be used in extreme weather conditions?

Yes, the pet door is constructed with durable, weather-resistant materials. Its dual-flap design ensures a tight seal, providing excellent insulation even in extreme weather conditions like heavy rain, snow, or high winds.
